General information
Lamp colour code :
- 865 cool daylight
Optical cover/lens type :
- Lens
Control interface :
- –
Protection class IEC :
- Safety class I (I)
CE mark :
- CE mark
Number of products on MCB (16 A type B) :
- 6
Light source engine type :
- LED
Operating and electrical
Input Voltage :
- 220-240 V
Input frequency :
- 50 or 60 Hz
Inrush current :
- 0.66 A
Power factor (min.) :
- 0.95
Controls and dimming
Dimmable :
- No
Mechanical and housing
Housing material :
- Aluminium
Optical cover/lens material :
- Polycarbonate
Optical cover/lens finish :
- Matte
Overall height :
- 99 mm
Overall diameter :
- 305 mm
Effective projected area :
- 0.06 m²
Colour :
- Grey
Dimensions (height x width x depth) :
- 99 x NaN x NaN mm
Approval and application
Ingress protection code :
- IP65 [ Dust penetration-protected, jet-proof]
Mech. impact protection code :
- IK06 [ 1 J]
Initial performance (IEC compliant)
Initial luminous flux (system flux) :
- 21000 lm
Luminous flux tolerance :
- +/-10%
Initial LED luminaire efficacy :
- 137 lm/W
Lamp colour temperature :
- 6500 K
Colour Rendering Index :
- >80
Initial chromaticity :
- (0.316, 0.332) SDCM<5
Initial input power :
- 154 W
Power consumption tolerance :
- +/-10%
Application conditions
Ambient temperature range :
- -20 to +45 °C
Product data
Full product code :
- 871951453661699
Order product name :
- BY518P LED210/CW PSU WB GM
EAN/UPC – product :
- 8719514536616
Order code :
- 911401647707
SAP numerator – quantity per pack :
- 1
Numerator – packs per outer box :
- 2
SAP material :
- 911401647707
Net Weight (Piece) :
- 2.290 kg
